Q-Switches

Acousto-optic Q-switches enable the control of the intensity of laser pulses within a laser cavity, utilizing acoustic waves to modulate light within a laser cavity. These switches enable precise control over the timing and duration of laser pulses, making them essential for applications requiring high-speed pulsing, such as laser engraving, medical lasers, and scientific research. By adjusting the acoustic waves, acousto-optic Q-switches can rapidly switch lasers between continuous and pulsed modes, allowing for efficient and reliable control of laser outputs. These devices are used for achieving high pulse energies and peak powers in laser systems.

Want to know more about Q-Switches?

    Specifications

    Cooling type: Water-cooled; Nd: YAg Lasers
    Interaction material: Fused Silica
    Wavelength: 1064 nm
    AR coating reflectivity: <0.2% per surface
    Damage threshold: >1000MW/cm2
    Transmission (single pass): >99.6%
    Diffraction efficiency: N/A
    Input impedance: N/A
    Static insertion loss: <= 6% at 50W laser power
    VSWR: < 1.2:1 (<1.4:1 at 50W RF power)
    RF power rating (maximum): 50W cw for Compressional acoustic mode 100W cw for Shear acoustic mode
    Water flow rate: >190cc/minute
    Water-cooling channel material: Stainless steel 316
    Recommended water temperature: +22 °C to +32 °C
    Thermal switch cut-off: +55 °C ±5 °C
    *Available frequency 24.00 / 27.12 / 40.68 / 68.00 (MHz)
    *Active aperture 1.6 / 2.0 / 3.0 / 4.0 / 5.0 / 6.5 / 8.0 (mm)
    *Acoustic mode Compressional / Shear
    *Water connector 4/6 mm OD straight push fit / right angle push fit;
